Peer Reviewed Validation

Investigating the Hydrodynamics of Intravenous Drug Infusions
International Journal of Pharmaceutics (February 2024)
MD Shujan Ali, Steven Castleberry

In this study, Genentech employs Large-Eddy Simulation (LES) turbulence modeling with M-Star CFD to simulate the flow and mixing of infusions in the bloodstream, aiming to improve the understanding of these adverse events. The results, which closely match benchtop tests, explore how varying fluid dynamics, needle orientation, and needle positioning affect infusion mixing, providing insights for developing safer intravenous formulations.

A numerical study on the mixing time prediction of miscible liquids with high viscosity ratios in turbulently stirred vessels
Chemical Engineering Science (February 2025)
Soroch Mirfasihi, Wrichik Basu, Philip Martin, Adam Kowalski, Claudio P. Fonte, Amir Keshmiri

Results from this joint study by the University of Manchester and Unilever show that GPU-based M-Star CFD outperformed CPU-based StarCCM+ in both speed and efficiency. Mixing processes are vital for ensuring product quality in industries like food and pharmaceuticals, especially when dealing with high-viscosity fluids. This study compares two CFD methodologies—RANS-FVM and LB-LES solvers—in predicting blending times for miscible liquids with contrasting viscosities, validated using experimental ERT data.

Trajectory-based breakup modelling for dense bubbly flows
Chemical Engineering Journal (November 2024)
Christian Weiland, Alexandra von Kameke, Michael Schlüter

The Hamburg University of Technology and of Applied Sciences employ M-Star CFD to simulate the breakup of gaseous bubbles in a liquid phase using a new Kelvin–Voigt-based spring–damper model derived from Lagrangian analysis. The model tracks individual bubbles through the flow, incorporating their history, and enables cost-efficient simulations across scales from laboratory vessels to large industrial reactors. Results, validated against optical experimental data from an aerated stirred tank reactor, demonstrate the model’s effectiveness in capturing bubble dynamics under varying stirrer frequencies.

Study of hydrodynamic stress in cell culture bioreactors via lattice-Boltzmann CFD simulations supported by micro-probe shear stress method
Biochemical Engineering Journal (May 2024)
Ondřej Šrom, Miroslav Šoóš, Maike Kuschel, Thomas Wucherpfennig, Jürgen Fitschen, Michael Schlüter

The University of Chemistry and Technology Prague, Boehringer Ingelheim Pharma, and the Hamburg University of Technology explore the application of shear-sensitive micro-probes to measure maximum hydrodynamic stress in mammalian cell cultivation across various bioreactor scales, from laboratory to industrial production. The study details the successful validation of experimental data with comprehensive M-Star CFD simulations, specifically using the Lattice-Boltzmann large eddy simulation method.

An in-silico analysis of hydrodynamics and gas mass transfer characteristics in scale-down models for mammalian cell cultures
Journal of Biotechnology (June 2024)
Alaina Anand, Madelynn McCahill, John Thomas, Aishwarya Sood, Jonathan Kinross, Aparajita Dasgupta, Aravindan Rajendran

Pfizer joins up with M-Star to investigate bioprocess scale-up challenges, focusing on factors like geometric variability and nutrient gradients. Using advanced computational fluid dynamics, it characterizes the Ambr® 250 bioreactor, revealing insights into agitation dynamics and mass transfer. The findings validate computational fluid dynamics for understanding bioreactor hydrodynamics and emphasize the importance of considering free-surface transfer mechanics for accurate scale-down model qualification in mammalian bioprocess development.

Computational fluid dynamics based digital twins of fixed bed bioreactors validate scaling principles for recombinant adeno-associated virus gene therapy manufacturing
Biotechnology and Bioengineering (May 2024)
Michael Hill, Colten White, Shaoying Wang, John Thomas, Brian DeVincentis, Nripen Singh

Passage Bio and M-Star explore gene therapy’s potential using recombinant adeno-associated virus (rAAV) and highlights gaps in manufacturing processes. Utilizing computational fluid dynamics, the study validates operating conditions for a predictive iCELLis® 500 scale-down model, addressing challenges in achieving consistent agitation rates and oxygen transfer across scales. Experimental validation confirms the efficacy of the novel scale-down model, offering insights crucial for optimizing rAAV manufacturing using fixed bed bioreactors.

A general approach for predicting convective heat transfer coefficients in turbulent systems
International Journal of Heat and Mass Transfer (March 2024)
John A. Thomas, Brian DeVincentis, Eric Janz, Ben Turner

M-Star presents an approach for predicting turbulent convective heat transfer coefficients using large eddy simulation. This is applied to agitated tanks, pipe flow systems, cylinders in crossflow, and tube bundles—all validating the generality and reliability of the theoretical model against expectations from experimentally derived empirical design correlations.

CFD-based bioreactor model with proportional-integral-derivative controller functionality for dissolved oxygen and pH
Biotechnology and Bioengineering (October 2023)
Christopher L. Oliveira, Zoe Pace, John A. Thomas, Brian DeVincentis, Chadakarn Sirasitthichoke, Susan Egan, Johnchan Lee

M-Star teams up with Bristol Myers Squibb to present a physics-based model with embedded PID controller logic for predicting cell culture fluid properties inside a stirred tank bioreactor. Agreement between the model prediction and measured bioreactor data is realized, and simulation runtimes are shown to be suitable for industrial research and design timescales.

Application of flux limiters to passive scalar advection for the lattice Boltzmann method
Computers & Mathematics with Applications (August 2023)
Brian DeVincentis, John Thomas

Given its wide application, the accurate and efficient solution to the advection-diffusion equation is of great interest. Here, M-Star CFD presents a new scalar advection algorithm for the lattice Boltzmann method—the flux limiter lattice advection (FLLA). The algorithm is designed to be conservative and have low memory requirements.

Experimental Determination and Computational Prediction of Blend Time in the USP Dissolution Testing Apparatus 1
Chemical Engineering Research and Design (May 2023)
Justin Pace, Chadakarn Sirasitthichoke, Piero M. Armenante

New Jersey Institute of Technology uses M-Star CFD to obtain the blend time for different operating conditions. Their computationally predicted and experimental blend times were found to be in agreement. They subsequently developed an empirical correlation for blend time which will help practitioners determine the exemplification of representative samples.

Experimental and computational characterization of mass transfer in high turndown bioreactors
Biotechnology Progress (February 2023)
Evan M. Schlaich, John A. Thomas, Lakshmi Kandari, Gabi Tremml, Anurag Khetan

Single-use bioreactors are extensively used for the clinical and commercial production of biologics. In this work, Bristol Myers Squibb works with M-Star to present a systematic investigation into free surface mass transfer and cell growth in high turndown single-use bioreactors. The results suggest an approach which potentially simplifies preculture operations.

CFD supported scale up of perfusion bioreactors in biopharma
Frontiers in Chemical Engineering (January 2023)
Maike Kuschel, Johannes Wutz, Mustafa Salli, Dominique Monteil, Thomas Wucherpfennig

M-Star Center Europe works with Boehringer Ingelheim to demonstrate how computational fluid dynamic models can be used for rational process design of intensified production processes in the biopharmaceutical industry. Computational fluid dynamics can be used to identify short circuit flows, assess mixing efficiencies, and adapt the perfusion setup.

Computational study of three-dimensional Lagrangian transport and mixing in a stirred tank reactor
Chemical Engineering Journal Advances (January 2023)
Christian Weiland, Eike Steuwe, Jürgen Fitschen, Marko Hoffmann, Michael Schlüter, Kathrin Padberg-Gehle, Alexandra von Kameke

The detection of compartments and dead zones as well as the estimation of the mixing efficiency in stirred tanks are of vital interest for a variety of biochemical and chemical processes. Here, researchers from Hamburg University of Technology, Hamburg University of Applied Sciences, and Leuphana University Lüneburg use M-Star CFD to numerically derive time-dependent 3D fluid velocity fields of a stirred tank reactor using the Lattice Boltzmann Method.

Predicting gas-liquid mass transfer rates in reactors using a bubble parcel model
Chemical Engineering Sciences (December 2022)
John A. Thomas, Brian DeVincentis, Navraj Hanspal, Richard O. Kehn

Understanding scale-up mechanisms is critical for reducing performance losses in industrial applications. In this article, M-Star works with Corteva Agriscience and SPX FLOW to present a transient large eddy simulation (LES) modeling approach for simulating the interlinked physics describing free surface hydrodynamics, multiphase mixing, reaction kinetics, and mass transport in bioreactor systems.

Modeling multiphase fluid flow, mass transfer, and chemical reactions in bioreactors using large-eddy simulation
Engineering in Life Sciences (November 2022)
Navraj Hanspal, Brian DeVincentis, John A. Thomas

Due to increased demand worldwide, the number and scale of industrial bioprocesses continues to expand at a rapid rate. Understanding scale-up mechanisms for reducing performance losses is critical for successful industrial applications. In this work, Corteva Agriscience works with M-Star to present a large-eddy-simulation–based approach to simulating a bioreactor system. It is shown that the presence of reactions can result in a non-uniform spatially varying species concentration field, the magnitude and extent of which is directly related to the reaction rates and the underlying variations in the local volumetric mass transfer coefficient.

Computational prediction of blend time in a large-scale viral inactivation process for monoclonal antibodies biomanufacturing
Biotechnology and Bioengineering (October 2022)
Chadakarn Sirasitthichoke, Duc Hoang, Poonam Phalak, Piero M. Armenante, Barak I. Barnoon, Ishaan Shandil

M-Star, together with Bristol Myers Squibb, New Jersey Institute of Technology, and University of Massachusetts Lowell, used a CFD model based on the Lattice Boltzmann method (LBM) to predict the blend time to homogenize a Triton X-100 solution added during a typical full-scale commercial VI process. The results obtained in this study were used to support actual production at the biomanufacturing site.

Blending and Cavern Formation within Non-Newtonian Fluids in Stirred Tanks: Application to Nuclear Waste Fluid Processing
Chemical Engineering Science (October 2022)
Sean Noble, Michael R. Poirier, John A. Thomas

M-Star collaborates with the Savannah River National Laboratory to predict the time-accurate fluid flow and mixing properties of non-Newtonian fluids. Across the range of fluids and systems, the simulations required no reparameterization or retuning between scenarios. This generality allowed them to model a nuclear waste processing unit operation.

Modeling gas release from a Bingham plastic slurry and deconvoluting measured data
Chemical Engineering Science (June 2022)
Michael R. Poirier, John A. Thomas, John M. Pareizs

M-Star works with the US Department of Energy performing Lattice Boltzmann computational fluid dynamics simulations to evaluate the impact of yield stress, impeller speed, and bubble size on the release of retained gas from a Bingham plastic slurry.

Modeling free surface gas transfer in agitated lab-scale bioreactors
Chemical Engineering Communications (June 2022)
John A. Thomas, Anisur Rahman, Johannes Wutz, Ying Wang, Brian DeVincentis, Brendan McGuire, Lei Cao

In this study, AbbVie works with M-Star to find that the free surface mass transfer rate in lab-scale systems is consistent with empirical relationships regardless of the mechanical action driving motion. Also, the computational approach is shown to be practical within the context of industrial analysis and design timescales.

An analysis of organism lifelines in an industrial bioreactor using Lattice-Boltzmann CFD
Engineering in Life Sciences (March 2022)
Cees Haringa

In this work by the Delft University of Technology, the performance of LB-LES in resolving substrate gradients in large-scale bioreactors is explored, combined with the inclusion of a Lagrangian biotic phase to provide the microbial perspective.

Predicting the diameters of droplets produced in turbulent liquid–liquid dispersion
AiCHE Journal (February 2022)
John A. Thomas, Brian DeVincentis, Johannes Wutz, Francesco Ricci

The droplet size distribution in liquid–liquid dispersions is a complex convolution of impeller speed, impeller type, fluid properties, and flow conditions. In this work with Boehringer Ingelheim, we present three a priori modeling approaches for predicting the droplet diameter distributions as a function of system operating conditions.

Computational prediction of the just-suspended speed, Njs, in stirred vessels using the Lattice Boltzmann method (LBM) coupled with a novel mathematical approach
Chemical Engineering Science (January 2022)
Chadakarn Sirasitthichoke, Baran Teoman, John Thomas, Piero M. Armenante

Determining the minimum agitation speed to achieve suspension of solids and liquids in a stirred vessel is of significant importance in industrial processes. In this article published jointly with M-Star and New Jersey Institute of Technology, the just-suspended speed is computationally predicted for a stirred, fully baffled vessel provided with different axial or radial impellers using M-Star CFD, coupled with a novel mathematical method.

Modeling Mass Transfer in Stirred Microbioreactors
Chemical Engineering Science (2022)
Hooman Farsani, Johannes Wutz, Brian DeVincentis, John A Thomas, Seyed Pouria Motevalian

Microbioreactors play a pivotal role in making biologic medicines. In fact, 10 of the top 15 selling drugs worldwide were made in a bioreactor. In this paper, M-Star and Pfizer present a generalized framework for modeling mass transfer in two-stage, stirred tank bioreactors to aid the scale-up process.

Validation of Novel Lattice Boltzmann Large Eddy Simulations (LB LES) for Equipment Characterization in Biopharma
Processes (2021)
Maike Kuschel, Jürgen Fitschen, Marko Hoffmann, Alexandra von Kameke, Michael Schlüter, Thomas Wucherpfennig

In this study, transient LB LES were applied to simulate a 3 L bioreactor system. The results were compared to novel 4D particle tracking (4D PTV) experiments, which resolve the motion of thousands of passive tracer particles on their journey through the bioreactor.

A CFD Digital Twin to Understand Miscible Fluid Blending
AAPS PharmSciTech (2021)
John Thomas, Kushal Sinha, Gayathri Shivkumar, Lei Cao, Marina Funck, Sherwin Shang, Nandkishor K. Nere

The mixing of stratified miscible fluids with widely different material properties is a common step in biopharmaceutical manufacturing processes. Differences between the fluid densities and viscosities, however, can lead to order-of-magnitude increase in blend times relative to the blending of single-fluid systems. In this work, M-Star and AbbVie build accelerated digital twins of a physical mixing tank to predict real-time fluid mechanics with a fidelity that rivals experimental data.

A Mechanistic Approach for Predicting Mass Transfer in Bioreactors
Chemical Engineering Science (2021)
John A. Thomas, Xiaoming Liu, Brian DeVincentis, Helen Hua, Grace Yao, Michael C. Borys, Kathryn Aron, Girish Pendse

In this work, M-Star pairs with Bristol Myers Squibb to propose, implement, and validate a mechanistic transport model for predicting oxygen transfer rates within stirred tank bioreactors. To begin, we describe the relevant conservation laws and key principles from turbulence theory that govern mass transfer.

Novel Evaluation Method to Determine the Local Mixing Time Distribution in Stirred Tank Reactors
Chemical Engineering Science: X (2021)
J. Fitschen, S. Hofmann, J. Wutz, A.v. Kameke, M. Hoffmann, T. Wucherpfennig, M. Schlüter

A novel image analysis will be presented in this study for the detailed characterization of mixing processes by taking into account the history of mixing. The method is based on the experimental determination of the local mixing time distribution by using a multi-color change caused by a pH-change in a bromothymol blue solution.

Time Scales and Turbulent Spectra above the Base of Stirred Vessels from Large Eddy Simulations
Flow, Turbulence and Combustion (2020)
Jason J. Giacomelli, Harry E. A. Van den Akker

Single-phase Large Eddy Simulations (LESs) have been conducted with M-Star CFD software to compute spectra and time scales of the turbulent flow field at positions above the base of a stirred tank as these time scales may be important to the application of solids suspension.

A Spectral Approach of Suspending Solid Particles in a Turbulent Stirred Vessel
Transport Phenomena and Fluid Mechanics (2020)
Jason J. Giacomelli, Harry E. A. Van den Akker

The 2015 Grenville-Mak-Brown (GMB) correlation for predicting the just suspended condition assumes that the length scale of the suspending eddy is equivalent to the particle diameter. This article investigates the role of the time scale of the relevant eddies with respect to the particle response time.
